Specifications: diameter: 320 to 127 mm thickness: 0.4 to 12.7 mm Length: 6 m above, and, in accordance with customer demand, supply and other specifications of steel pipe

2.5" inch steel pipe




2.5 inch steel pipe
Wall thickness:Sch5-Sch160XXS


Standard:ASME B36.10M-1996 ,API ,ANSI ,GB, SH,HG, MSS,JIS,DIN
Material:ASTM A106 GRB/ A53 GRB/ API 5L GRB/ API 5 CT /Q345/A335/ST37/ST52/ST42


2.5 inch steel pipe

1 Commodity name

2.5 inch steel pipe

2 Standard



DIN17175,DIN1626,DIN2448,DIN17120,API 5L, API 5CT, ASTM A106,
ASTM A53,ASTM A179,ASTM A210,ASTM A36,JISG3454,JISG3455,
JISG3556,GOST8732,GOST8731

3 Outer Diameter

20-1020mm

4 Wall Thickness

1-200mm

5 Length

8-9m,or according to your request

6 Packing

 in bundles or according to the customers' request

7 Payment Term

30%T/T in advance,the balance against B/L copy

8 Delivery Time

15 days after we received the advanced deposit

9 material

Gr. B, Gr. C; X42,X46,X52,X60,J55,K55,N80; st37,
st42,st42-2,st45.8,st52,Gr 20,STPG410,STPG480,STB410

12Cr1MoV,P22(10CrMo910)T91,P91,P9,T9,WB36 ,
Cr5Mo(P5,STFA25,T5,)15CrMo(P11,P12,STFA22),
13CrMo44,Cr5Mo,15CrMo,25CrMo,30CrMo,40CrMo

10 Usage

widely used in petroleum, chemical industry, electricity, boiler, etc

11 Export to these country

Middle east countries, India, USA,  Canada , Chile, Colombia,

12 Certificates

API5L ,API5CT ,ISO ,CE

 2.5 inch steel pipe

2.5 inch steel pipe
