Specifications: diameter: 320 to 127 mm thickness: 0.4 to 12.7 mm Length: 6 m above, and, in accordance with customer demand, supply and other specifications of steel pipe

A53A/A53B、SA53A/B,A500 B/C Structural Steel Pipe




NETGMS.COM NEWSINDA STEEL PIPE CO.LTD welded tube and line pipe, offering ASTM A 500 Grade B ,Grade C Structural Pipe in standard untested Schedule 10 and Schedule 40 sizes.

•    Can be ordered to meet Grade B and C specifications
•    Available from stock in standard 21' 24' and 42' lengths
A500 B/C Structural Steel Pipe

PIPE SIZE OD GAUGE LBS PER FEET 21' PCS FT PER LBS 24' PCS FT PER LBS 42' PCS FT PER LBS
1" 1.315 0.133 1.68 60 1260 2117 60 1440 2419
1 1/4" 1.66 0.109 1.805 44 924 1668 44 1056 1906
1 1/4" 1.66 0.140 2.273 44 924 2100 44 1056 2400
1 1/2" 1.9 0.109 2.085 37 777 1620 37 888 1851
1 1/2" 1.9 0.145 2.718 37 777 2112 37 888 2414
2" 2.375 0.109 2.638 29 609 1607
2" 2.375 0.154 3.653 29 609 2225 29 696 2542 29 1218 4449
2" 2.375 0.218 5.022 19 399 2004       19 798 4008
2 1/2" 2.875 0.203 5.79 19 399 2310       19 798 4620
3" 3.5 0.219 7.58 19 399 3024       19 798 6049
4" 4.5 0.120 5.61 10 210 1178       10 420 2356
4" 4.5 0.237 10.79 10 210 2266       10 420 4532
6" 6.625 0.134 9.289 7 147 1365       7 294 2731
6" 6.625 0.188 12.92 7 147 1899       7 294 3798
6" 6.625 0.250 17.02 7 147 2502       7 294 5004
6" 6.625 0.280 18.97 7 147 2789       7 294 5577



A53A/A53B、SA53A/B Structural Steel Pipe

A53A/A53B、SA53A/B Structural Steel Pipe

Type Structure Pipe
Main Material 10、20、35、45、Q345、15CrMo、12Cr1MoV、A53A、A53B、SA53A、SA53B
Operational Standard GB/T8162-1999    ISO2937 ASTM A53   ASTMA106  JIS G 3441BS  EN 10210-1
Specification OD:6-610mm WT:1.5-40mm
For use Ordinary structure and mechanical structure, greatly applied in all kinds of structural tubes in building, machinery, transportation, airline,oil exploitation and other industries.

Chemical composition & Mechanical properties

   Chemical composition(%) Mechanical properties
C Si Mn P S Ni Cr Cu
Yield strength Tensile strength Elongation
  Min Max Min Max Min Max Max Max MPa MPa δ(%)
20 0.17 0.24 0.17 0.37 0.35 0.65 0.035 0.035 0.3 0.25 0.25 245 390 20
45 0.42 0.5 0.17 0.37 0.5 0.8 0.035 0.035 ≤0.25 ≤0.25 ≤0.25 335 590 14
16Mn 0.12 0.2 0.2 0.55 1.2 1.6 0.035 0.035 ≤0.25 ≤0.25 ≤0.25 325 490 21
45Mn2 0.42 0.49 0.2 0.4 1.4 1.8 0.035 0.035 0.25 0.25 0.25 560 700 13
27SiMn 0.24 0.32 1.1 1.4 1.1 1.4 0.035 0.035 0.3 0.3 0.2 500 680 14
