Specifications: diameter: 320 to 127 mm thickness: 0.4 to 12.7 mm Length: 6 m above, and, in accordance with customer demand, supply and other specifications of steel pipe

DIN2448 DIN1629 steel pipe


1.OD:8" to 36"

2.WT:6-20mm
3.Metarial: ST37-ST52 GR.B X42-X70
4.Certification: API spac 5L ISO9001


Inspection & Certification
(1) Mill Test Certificate EN10204/3.1B
(2) Certification: ISO, API, PED, DNV, ABS, Lloyds etc.
(3) Third party inspection: SGS,BV, Lloyds etc.

Outside dia. In inch Outside dia. In mm Wall thickness(mm)
 1/2" 21.3mm 2.00mm
3/4" 26.9mm 2.30mm
1" 33.7mm 2.60mm
1 1/4" 42.4mm 2.60mm
1 1/2" 48.3mm 2.60mm
2" 60.3mm 2.90mm
2 1/2" 76.1mm 2.90mm
3" 88.9mm 3.20mm
4" 114.3mm 3.60mm
5" 139.7mm 4.00mm
6" 168.3mm 4.50mm
8" 219.1mm 6.00mm
10" 273.1mm 6.50mm
12" 323.9mm 7.10mm

DIN2448 DIN1629 steel pipe

Packing
(1) Packing in bundles,
(2) Surface: Varnish coating
(3) Ends: Beveled or square cut, Plastic capped.
(4) The pipes also can be 3PE or FBE or Galv. coated.

Delivery
(1) DIN2448 1629 pipe Payment: T/T 30% or 100% Irrevocable L/C at sight

(2) Delivery: FOB / CFR / CIF
(3) Delivery Lead Time: Within 45 days after the receipt of L/C
(4) Minimum order : 10 tons to 60 tons per size acc. to size or grade.
(5) Supply Ability: 4000MT/month



Products

OD

 W.T.

Standard

Materials

Length

Seamless steel pipe

8" TO 36"

SCH20,30,40,60,

STD,XS,80

ASTMA106GR.B

ASTM A53GR.B

EN10204/3.1B

DIN1629-1948

ST45/ST52

ST35/ST44

E355/16MN

P265GH

P245/265TR1

5.8m, 6m,

5m to12m random

ERW Steel pipe

3" TO 24"

SCH20,30,40,60,

STD,XS,80

ASTM A53GR.B

EN10216-1

EN10217-1

St 44.0 /ST 52

P245/265TR1

5.8m, 6m,

5m to12m random

Sprial steel pipe

8" TO 36"

SCH20,30,40,60,

STD,XS,80

SY/T5037-2001

Q235

5.8m, 6m,

5m to12m random



上一篇:api 5l erw x42 x60 line pipe

下一篇:ASTM A335 Seamless Pipe
